Dalton GR Series battery is real GEL batteries engineered specifically to satisfy the need for frequent deep-cycle from Photovoltaic(PV) and renewable energy storage applications. The true GEL technology, GR series batteries provide stability and longevity you need for your everyday renewable energy needs.;
VIEW SPECIFICATIONSGOL Series
Specifications
Dalton GR Series battery is real GEL batteries engineered specifically to satisfy the need for frequent deep-cycle from Photovoltaic(PV) and renewable energy storage applications.
The true GEL technology, GR series batteries provide stability and longevity you need for your everyday renewable energy needs.
| Golf (AGM) - 6V | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Model | Nominal Voltage (V) | Capacity (20hr) | Capacity (10hr) | Dimension (mm) | Net Weight | Gross Weight | Terminal | |||
| Length | Width | Height | Total Height | |||||||
| GR 225-6 | 6 | 224.00 HR | 210.00 HR | 260.00 | 180.00 | 247.00 | 253.00 | 30.50kg | 40.00kg | F11 |
| GR 245-6 | 6 | 245.00 HR | 232.00 HR | 243.00 | 287.00 | 275.00 | 275.00 | 32.40kg | 32.90kg | F11 |
| Golf (AGM) - 8V | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Model | Nominal Voltage (V) | Capacity (20hr) | Capacity (10hr) | Dimension (mm) | Net Weight | Gross Weight | Terminal | |||
| Length | Width | Height | Total Height | |||||||
| GR 170-8 | 8 | 182.00 HR | 170.00 HR | 260.00 | 180.00 | 252.00 | 274.00 | 30.80kg | 40.30kg | UA1 |
| GR 200-8 | 8 | 210.00 HR | 190.00 HR | 260.00 | 182.00 | 295.00 | 298.00 | 40.50kg | 50.00kg | F11 |
| Golf (AGM) - 12V | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Model | Nominal Voltage (V) | Capacity (20hr) | Capacity (10hr) | Dimension (mm) | Net Weight | Gross Weight | Terminal | |||
| Length | Width | Height | Total Height | |||||||
| GR 7-12 | 12 | 7.00 HR | 6.77 HR | 151.00 | 65.00 | 93.50 | 99.00 | 2.30kg | 2.80kg | F2 |
| GR 9-12 | 12 | 9.00 HR | 8.43 HR | 151.00 | 65.00 | 111.00 | 117.00 | 2.750kg | 3.00kg | F2 |
| GR 150-12 | 12 | 150.00 HR | 143.00 HR | 327.00 | 180.00 | 274.00 | 274.00 | 42.20kg | 42.70kg | F11 |
