LHR Series
LHR Series
LHR batteries are general-purpose batteries designed to fulfill the highest standards in performance and safety, They are ideal for security and alarm systems, emergency lighting, signaling, and any other UPS application where compact and reliable back-up power is key.;
VIEW SPECIFICATIONSSpecifications
LHR batteries are general-purpose batteries designed to fulfill the highest standards in performance and safety, They are ideal for security and alarm systems, emergency lighting, signaling, and any other UPS application where compact and reliable back-up power is key
| LHR Series - 2V | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Model | Nominal Voltage (V) | Capacity (20hr) | Capacity (10hr) | Dimension (mm) | Net Weight | Gross Weight | Terminal | |||
| Length | Width | Height | Total Height | |||||||
| LHR 65-2 | 2 | - | 65.00 HR | 170.00 | 72.00 | 205.00 | 212.00 | 5.20kg | 5.70kg | F6 |
| LHR 80-2 | - | 80.00 HR | 170.00 | 72.00 | 205.00 | 212.00 | 5.60kg | 6.10kg | F6 | |
| LHR 100-2 | 2 | 104.00 HR | 100.00 HR | 170.00 | 72.00 | 205.00 | 214.00 | 5.80kg | 6.30kg | F6 |
| LHR 130-2 | 2 | - | 130.00 HR | 170.00 | 98.00 | 205.00 | 212.00 | 8.00kg | 8.50kg | F7 |
| LHR 150-2 | 2 | - | 150.00 HR | 170.00 | 98.00 | 205.00 | 212.00 | 8.80kg | 9.30kg | F7 |
| LHR 200-2 | 2 | 208.00 HR | 200.00 HR | 170.00 | 110.00 | 328.00 | 337.00 | 13.80kg | 14.30kg | F11 |
| LHR 300-2 | 2 | 312.00 HR | 300.00 HR | 170.00 | 150.00 | 330.00 | 339.00 | 18.90kg | 19.40kg | F11 |
| LHR 400-2 | 2 | 414.00 HR | 400.00 HR | 175.00 | 210.00 | 330.00 | 339.00 | 25.70kg | 26.20kg | F11 |
| LHR 500-2 | 2 | 518.00 HR | 500.00 HR | 175.00 | 240.00 | 330.00 | 338.00 | 30.20kg | 30.70kg | F11 |
| LHR 600-2 | 2 | 622.00 HR | 600.00 HR | 175.00 | 300.00 | 330.00 | 340.00 | 36.80kg | 37.30kg | F11 |
| LHR 600-2 | 2 | 622.00 HR | 600.00 HR | 175.00 | 300.00 | 330.00 | 340.00 | 36.80kg | 37.30kg | F11 |
| LHR 600-2 | 2 | 622.00 HR | 600.00 HR | 175.00 | 300.00 | 330.00 | 340.00 | 36.80kg | 37.30kg | F11 |
| LHR 800-2 | 2 | 830.00 HR | 800.00 HR | 175.00 | 410.00 | 330.00 | 340.00 | 46.00kg | 46.50kg | F11 |
| LHR 1000-2 | 2 | 1036.00 HR | 1000.00 HR | 175.00 | 475.00 | 328.00 | 338.00 | 56.00kg | 56.50kg | F11 |
| LHR 1500-2 | 2 | 1556.00 HR | 1500.00 HR | 400.00 | 350.00 | 345.00 | 382.00 | 96.60kg | 97.10kg | F11 |
| LHR 2000-2 | 2 | 2120.00 HR | 2000.00 HR | 490.00 | 350.00 | 339.00 | 349.00 | 116.00kg | 116.50kg | F11 |
| LHR 3000-2 | 2 | 3200.00 HR | 3000.00 HR | 709.00 | 350.00 | 337.00 | 349.00 | 190.00kg | 190.50kg | F11 |
| LHR 3000-2 | 2 | 3200.00 HR | 3000.00 HR | 709.00 | 350.00 | 337.00 | 349.00 | 190.00kg | 190.50kg | F11 |
| LHR Series - 6V | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Model | Nominal Voltage (V) | Capacity (10hr) | Dimension (mm) | Net Weight | Gross Weight | Terminal | ||||
| Length | Width | Height | Total Height | |||||||
| LHR 200-6 | 6 | 200.00 HR | 321.00 | 176.00 | 226.00 | 229.00 | 31.00kg | 31.50kg | F11 | |
| LHR 250-6 | 6 | 250.00 HR | 295.00 | 178.00 | 345.00 | 348.00 | 37.00kg | 37.50kg | F11 | |
| LHR 300-6 | 6 | 300.00 HR | 295.00 | 178.00 | 345.00 | 348.00 | 48.50kg | 49.00kg | F11 | |
| LHR Series - 12V | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Model | Nominal Voltage (V) | Capacity (20hr) | Capacity (10hr) | Dimension (mm) | Net Weight | Gross Weight | Terminal | |||
| Length | Width | Height | Total Height | |||||||
| LHR 5 - 12 | 12 | 5.00 HR | 4.73 HR | 90.00 | 70.00 | 101.00 | 107.00 | 1.4kg | 1.40kg | F2 |
| LHR 7-12 | 12 | 7.00 HR | 6.4 HR | 151.00 | 65.00 | 94.00 | 100.00 | 2.1kg | 2.15kg | F2 |
| LHR 7.2-12 | 12 | 7.71 HR | 7.20 HR | 151.00 | 65.00 | 93.50 | 99.00 | 2.5kg | 2.50kg | F2 |
| LHR 9-12 | 12 | 9.00 HR | 8.20 HR | 151.00 | 65.00 | 94.00 | 100.00 | 2.5kg | 2.55kg | F2 |
| LHR 12-12 | 12 | 13.90 HR | 13.00 HR | 151.00 | 98.00 | 95.00 | 101.00 | 4kg | 4.00kg | F2 |
| LHR 20-12 | 12 | 20.80 HR | 18.00 HR | 181.50 | 77.00 | 168.00 | 168.00 | 6.1kg | 6.10kg | F3/F12 |
| LHR 22-12 | 12 | 22.00 HR | 18.00 HR | 181.50 | 77.00 | 167.50 | 167.50 | 6.2kg | 6.20kg | F3 |
| LHR 26-12 | 12 | 28.00 HR | 26.00 HR | 166.00 | 175.00 | 125.00 | 125.00 | 8.4kg | 8.40kg | F3 |
| LHR 35-12 | 12 | 35.00 HR | 30.60 HR | 195.00 | 130.00 | 164.00 | 180.00 | 11.2kg | 11.20kg | F5/F6 |
| LHR 40-12 | 12 | 40.80 HR | 40.00 HR | 197.00 | 165.00 | 170.00 | 170.00 | 13.5kg | 13.50kg | F6 |
| LHR 45-12 | 12 | 47.20 HR | 45.00 HR | 197.00 | 165.00 | 170.00 | 170.00 | 14.5kg | 14.50kg | F6 |
| LHR 50-12 | 12 | 52.60 HR | 50.00 HR | 229.00 | 138.00 | 210.00 | 216.00 | 17kg | 17.00kg | F6/F9 |
| LHR 55-12 | 12 | 57.80 HR | 55.00 HR | 229.00 | 138.00 | 210.00 | 230.00 | 17.7kg | 17.70kg | F9 |
| LHR 65-12 | 12 | 67.00 HR | 65.00 HR | 348.00 | 167.00 | 178.00 | 178.00 | 21.2kg | 21.20kg | F6 |
| LHR 75-12 | 12 | 77.20 HR | 75.00 HR | 260.00 | 168.00 | 208.00 | 214.00 | 22.3kg | 22.30kg | F6 |
| LHR 85-12 | 12 | 92.80 HR | 90.00 HR | 306.00 | 168.00 | 208.00 | 214.00 | 26.8kg | 26.80kg | F6 |
| LHR 100-12 | 12 | 103.00 HR | 100.00 HR | 330.00 | 173.00 | 212.00 | 232.00 | 30.6kg | 30.60 | F10/F11 |
| LHR 105-12 | 12 | - | 105.00 HR | 410.00 | 176.00 | 225.00 | 225.00 | 32.5kg | 32.50kg | F11 |
| LHR 120-12 | 12 | 123.60 HR | 120.00 HR | 408.00 | 177.00 | 225.00 | 225.00 | 37.3kg | 37.30kg | F10/F11 |
| LHR 125-12 | 12 | 130.00 HR | 125.00 HR | 345.00 | 172.00 | 274.00 | 280.00 | 47.3kg | 47.30kg | F11 |
| LHR 150-12 | 12 | 154.60 HR | 150.00 HR | 483.00 | 170.00 | 238.00 | 238.00 | 43.5kg | 43.50kg | F10/F11 |
| LHR 200-12 | 12 | 206.00 HR | 200.00 HR | 522.00 | 240.00 | 218.00 | 224.00 | 62.2kg | 62.20kg | F11 |
| LHR 250-12 | 12 | 258.00 HR | 250.00 HR | 522.00 | 268.00 | 220.00 | 226.00 | 70.6kg | 70.60kg | F11 |
| LHR 275-12 | 12 | 281.00 HR | 275.00 HR | 522.00 | 268.00 | 220.00 | 226.00 | 72.8kg | 72.80kg | F11 |
