HR Series
HR Series
Dalton HR high discharge rate is representative of the charge and discharge capability of the AGM battery with respect to the ordinary rate. The high-rate battery is divided into a discharge rate and a charge rate. HR series is especially designed for heavy load discharge applications with 8 to 15 years design life in float service. By using strong grids and specially designed active material the HR series offers stable performance .;
VIEW SPECIFICATIONSSpecifications
Dalton HR high discharge rate is representative of the charge and discharge capability of the AGM battery with respect to the ordinary rate. The high-rate battery is divided into a discharge rate and a charge rate. HR series is especially designed for heavy load discharge applications with 8 to 15 years design life in float service. By using strong grids and specially designed active material the HR series offers stable performance
| HR Series - 2V | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Model | Nominal Voltage (V) | Capacity (20hr) | Capacity (10hr) | Dimension (mm) | Net Weight | Gross Weight | Terminal | |||
| Length | Width | Height | Total Height | |||||||
| HR 100-2 | 2 | 105.00 HR | 100.00 HR | 170.00 | 72.00 | 205.00 | 214.00 | 5.80kg | 6.30kg | F6 |
| HR 150-2 | 2 | 157.00 HR | 150.00 HR | 170.00 | 98.00 | 205.00 | 214.00 | 8.40kg | 8.90kg | F7 |
| HR 200-2 | 2 | 212.00 HR | 200.00 HR | 170.00 | 110.00 | 328.00 | 350.00 | 12.70kg | 13.00kg | F11 |
| HR 250-2 | 2 | 266.00 HR | 250.00 HR | 170.00 | 110.00 | 328.00 | 350.00 | 14.30kg | 14.70kg | F11 |
| HR 300-2 | 2 | 322.00 HR | 300.00 HR | 170.00 | 150.00 | 330.00 | 350.00 | 17.70kg | 18.30kg | F11 |
| HR 450-2 | 2 | 478.00 HR | 450.00 HR | 175.00 | 210.00 | 330.00 | 350.00 | 24.30kg | 24.80kg | F11 |
| HR 500-2 | 2 | 524.00 HR | 500.00 HR | 175.00 | 240.00 | 327.00 | 347.00 | 29.00kg | 29.50kg | F11 |
| HR 600-2 | 2 | 630.00 HR | 600.00 HR | 175.00 | 300.00 | 330.00 | 350.00 | 35.70kg | 36.20kg | F11 |
| HR 800-2 | 2 | 848.00 HR | 800.00 HR | 175.00 | 410.00 | 330.00 | 350.00 | 50.40kg | 50.90kg | F11 |
| HR 1000-2 | 2 | 1060.00 HR | 1000.00 HR | 175.00 | 475.00 | 328.00 | 350.00 | 57.80kg | 58.30kg | F11 |
| HR 1200-2 | 2 | 1280.00 HR | 1200.00 HR | 175.00 | 475.00 | 328.00 | 350.00 | 63.80kg | 64.30kg | F11 |
| HR 1500-2 | 2 | 1599.00 HR | 1500.00 HR | 403.00 | 354.00 | 339.00 | 349.00 | 93.50kg | 94.00kg | F11 |
| HR 1800-2 | 2 | 1890.00 HR | 1800.00 HR | 403.00 | 354.00 | 339.00 | 349.00 | 101.00kg | 101.50kg | F11 |
| HR 2000-2 | 2 | 2120.00 HR | 2000.00 HR | 490.00 | 350.00 | 339.00 | 349.00 | 117.50kg | 118.00kg | F11 |
| HR 3000-2 | 2 | 3180.00 HR | 3000.00 HR | 709.00 | 350.00 | 337.00 | 347.00 | 176.40kg | 177.00kg | F11 |
| HR 120-2 | 2 | 124.80 HR | 120.00 HR | 170.00 | 98.00 | 205.00 | 214.00 | 7.20kg | 7.70kg | F7 |
| HR 350-2 | 2 | 372.00 HR | 350.00 HR | 170.00 | 110.00 | 330.00 | 350.00 | 19.30kg | 19.80kg | F11 |
| HR 400-2 | 2 | 416.00 HR | 400.00 HR | 175.00 | 210.00 | 330.00 | 350.00 | 24.30kg | 24.80kg | F11 |
| HR 2500-2 | 2 | 2626.00 HR | 2500.00 HR | 490.00 | 350.00 | 339.00 | 349.00 | 133.60kg | 134.00kg | F11 |
| HR Series - 6V | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Model | Nominal Voltage (V) | Capacity (20hr) | Capacity (10hr) | Dimension (mm) | Net Weight | Gross Weight | Terminal | |||
| Length | Width | Height | Total Height | |||||||
| HR 1-6 | 6 | 1.00 HR | 0.95 HR | 51.00 | 42.00 | 51.00 | 57.50 | 0.25kg | 0.75kg | F2 |
| HR 1.3-6 | 6 | 1.30 HR | 1.13 HR | 97.00 | 24.00 | 51.50 | 57.50 | 0.29kg | 0.79kg | F2 |
| HR 2-6 | 6 | 2.00 HR | 1.89 HR | 43.00 | 37.00 | 76.00 | 76.00 | 0.34kg | 0.84kg | F2 |
| HR 2.8-6 | 6 | 2.80 HR | 2.65 HR | 66.00 | 33.00 | 97.00 | 103.00 | 0.55kg | 1.00kg | F2 |
| HR 2.8-6L | 6 | 2.80 HR | 2.60 HR | 134.00 | 35.00 | 61.00 | 67.00 | 0.57kg | 1.00kg | F2 |
| HR 3.4-6 | 6 | 3.40 HR | 3.31 HR | 134.00 | 34.00 | 60.00 | 66.00 | 0.67kg | 1.10kg | F2 |
| HR 3.8-6 | 6 | 3.80 HR | 3.50 HR | 67.00 | 34.00 | 124.00 | 124.00 | 0.74kg | 1.20kg | F2 |
| HR 4-6 | 6 | 4.00 HR | 3.72 HR | 70.00 | 47.00 | 100.00 | 106.00 | 0.65kg | 1.00kg | F2 |
| HRR 4.5-6 | 6 | 4.50 HR | 4.26 HR | 70.00 | 47.00 | 100.00 | 106.00 | 0.75kg | 1.20kg | F2 |
| HR 5-6 | 6 | 5.00 HR | 4.73 HR | 70.00 | 47.00 | 100.00 | 106.00 | 0.81kg | 1.30kg | F2 |
| HR 5.4-6 | 6 | 5.40 HR | 5.06 HR | 70.00 | 47.00 | 101.00 | 106.00 | 0.80kg | 1.30kg | F2 |
| HR 6-6 | 6 | 6.00 HR | 5.52 HR | 70.00 | 47.00 | 100.00 | 106.00 | 0.90kg | 1.40kg | F2 |
| HR 7-6 | 6 | 7.00 HR | 6.53 HR | 151.00 | 34.00 | 94.00 | 100.00 | 1.00kg | 1.50kg | F2 |
| HR 7.2-6 | 6 | 7.20 HR | 6.69 HR | 151.00 | 34.00 | 94.00 | 100.00 | 1.05kg | 1.50kg | F2 |
| HR 7.5-6 | 6 | 7.50 HR | 7.02 HR | 151.00 | 34.00 | 94.00 | 100.00 | 1.26kg | 1.75kg | F2 |
| HR 8.5-6 | 6 | 8.50 HR | 7.68 HR | 151.00 | 34.00 | 94.00 | 100.00 | 1.20kg | 1.70kg | F2 |
| HR 8.5-6T | 6 | 8.50 HR | 7.90 HR | 98.00 | 56.00 | 118.00 | 120.00 | 1.28kg | 1.78kg | F2 |
| HR 10-6 | 6 | 10.00 HR | 9.32 HR | 151.00 | 50.50 | 94.00 | 100.00 | 1.54kg | 2.00kg | F2 |
| HR 12-6 | 6 | 12.00 HR | 11.2 HR | 151.00 | 50.50 | 94.00 | 100.00 | 1.75kg | 2.20kg | F2 |
| HR 14-12 | 6 | 14.00 HR | 12.60 HR | 151.00 | 50.50 | 94.00 | 100.00 | 2.05kg | 2.50kg | F1/F2 |
| HR 36-6 | 6 | 36.00 HR | 34.00 HR | 161.00 | 87.00 | 163.00 | 169.00 | 5.50kg | 6.00kg | F2/F3 |
| HR 60-6 | 6 | 61.80 HR | 60.00 HR | 185.00 | 112.00 | 205.00 | 205.00 | 9.10kg | 9.60kg | F2/F3 |
| HR 120-6 | 6 | 124.80 HR | 120.00 HR | 280.00 | 128.00 | 203.00 | 203.00 | 16.80kg | 17.30kg | F6 |
| HR 150-6 | 6 | 156.40 HR | 150.00 HR | 260.00 | 180.00 | 247.00 | 253.00 | 23.10kg | 23.60kg | F7 |
| HR 200-6 | 6 | 208.00 HR | 200.00 HR | 322.00 | 178.00 | 226.00 | 232.00 | 30.30kg | 30.80kg | F8 |
| HR Series - 12V | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Model | Nominal Voltage (V) | Capacity (20hr) | Capacity (10hr) | Dimension (mm) | Net Weight | Gross Weight | Terminal | |||
| Length | Width | Height | Total Height | |||||||
| HR 0.8-12 | 12 | 0.80 HR | 0.76 HR | 96.00 | 25.00 | 62.00 | 62.00 | 0.30kg | 0.80kg | F2 |
| HR 1.3-12 | 12 | 1.30 HR | 1.13 HR | 97.00 | 43.00 | 52.00 | 58.00 | 0.55kg | 1.00kg | F2 |
| HR 1.9-12 | 12 | 1.90 HR | 1.80 HR | 178.00 | 35.00 | 60.00 | 66.00 | 0.80kg | 1.30kg | F2 |
| HR 2.2-12 | 12 | 2.20 HR | 2.05 HR | 70.50 | 47.50 | 97.00 | 103.00 | 0.82kg | 1.30kg | F2 |
| HR 2.4-12 | 12 | 2.40 HR | 2.16 HR | 178.00 | 35.00 | 60.00 | 66.00 | 0.85kg | 1.30kg | F1/F2 |
| HR 2.6-12S | 12 | 2.60 HR | 2.30 HR | 70.00 | 48.00 | 98.00 | 104.00 | 0.85kg | 1.30kg | F2 |
| HR 2.6-12 | 12 | 2.60 HR | 2.30 HR | 178.00 | 35.00 | 60.00 | 66.00 | 0.95kg | 1.30kg | F2 |
| HR 2.8-12 | 12 | 2.80 HR | 2.65 HR | 132.00 | 33.00 | 98.00 | 104.00 | 1.10kg | 1.60kg | F2 |
| HR 2.9-12 | 12 | 2.90 HR | 2.70 HR | 79.00 | 56.00 | 99.00 | 105.00 | 1.15kg | 1.65kg | F2 |
| HR 3.4-12 | 12 | 3.40 HR | 3.10 HR | 134.00 | 67.00 | 61.00 | 67.00 | 1.25kg | 1.75kg | F2 |
| HR 4.-12 | 12 | 4.00 HR | 3.72 HR | 90.00 | 70.00 | 101.00 | 107.00 | 1.40kg | 1.90kg | F2 |
| HR 4-12L | 12 | 4.00 HR | 3.78 HR | 195.00 | 47.00 | 70.00 | 76.00 | 1.60kg | 2.10kg | F2 |
| HR 4.5-12 | 12 | 4.50 HR | 4.19 HR | 90.00 | 70.00 | 101.00 | 107.00 | 1.45kg | 1.95kg | F2 |
| HR 5-12 | 12 | 5.00 HR | 4.73 HR | 90.00 | 70.00 | 101.00 | 107.00 | 1.60kg | 2.10kg | F2 |
| HR 5-12L | 12 | 5.00 HR | 4.73 HR | 151.00 | 53.00 | 93.00 | 99.00 | 1.75kg | 2.25kg | F2 |
| HR 6-12 | 12 | 6.00 HR | 5.67 HR | 151.00 | 65.00 | 93.50 | 99.00 | 1.85kg | 2.35kg | F2 |
| HR 6.2-12 | 12 | 6.20 HR | 6.05 HR | 151.00 | 65.00 | 93.50 | 99.00 | 1.90kg | 2.40kg | F2 |
| HR 6.5-12 | 12 | 6.50 HR | 6.15 HR | 151.00 | 65.00 | 93.50 | 99.00 | 1.95kg | 2.45kg | F2 |
| HR 7-12 | 12 | 7.00 HR | 6.53 HR | 151.00 | 65.00 | 93.50 | 99.00 | 2.00kg | 2.50kg | F2 |
| HR 7.2-12 | 12 | 7.20 HR | 6.70 HR | 151.00 | 65.00 | 93.50 | 99.00 | 2.15kg | 2.65kg | F2 |
| HR 7.5-12 | 12 | 7.50 HR | 7.09 HR | 151.00 | 65.00 | 93.50 | 99.50 | 2.30kg | 2.80kg | F2 |
| HR 8.5-12 | 12 | 8.42 HR | 7.82 HR | 151.00 | 65.00 | 93.50 | 99.00 | 2.40kg | 2.90kg | F2 |
| HR 9-12 | 12 | 9.00 HR | 8.51 HR | 151.00 | 65.00 | 93.50 | 99.50 | 2.45kg | 2.95kg | F2 |
| HR 10-12 | 12 | 10.00 HR | 9.30 HR | 151.00 | 65.00 | 111.00 | 117.00 | 3.11kg | 3.61kg | F2 |
| HR 12-12 | 12 | 12.00 HR | 11.20 HR | 151.00 | 98.00 | 95.00 | 101.00 | 3.40kg | 3.90kg | F2 |
| HR 14-12 | 12 | 14.00 HR | 13.20 HR | 151.00 | 98.00 | 95.00 | 101.00 | 3.90kg | 4.40kg | F1/F2 |
| HR 15-12 | 12 | 15.00 HR | 14.20 HR | 181.50 | 77.00 | 167.50 | 167.50 | 4.56kg | 5.06kg | F3 |
| HR 17-12 | 12 | 17.00 HR | 15.80 HR | 181.50 | 77.00 | 167.50 | 167.50 | 5.00kg | 5.50kg | F3/F12 |
| HR 18-12 | 12 | 18.00 HR | 17.00 HR | 181.50 | 77.00 | 167.50 | 167.50 | 5.30kg | 5.80kg | F3/F12 |
| HR 20-12 | 12 | 20.00 HR | 18.90 HR | 181.50 | 77.00 | 167.50 | 167.50 | 5.70kg | 6.10kg | F3/F12 |
| HR 24-12 | 12 | 24.00 HR | 22.70 HR | 166.00 | 175.00 | 125.00 | 125.00 | 7.20kg | 7.70kg | F3/F12 |
| HR 26-12 | 12 | 26.00 HR | 24.60 HR | 166.50 | 175.00 | 125.00 | 125.00 | 8.00kg | 8.50kg | F3/F12 |
| HR 28-12 | 12 | 28.00 HR | 26.30 HR | 166.00 | 175.00 | 125.00 | 125.00 | 8.40kg | 8.90kg | F3/F12 |
| HR 30-12 | 12 | 30.00 HR | 28.40 HR | 166.00 | 175.00 | 125.00 | 125.00 | 8.80kg | 9.30kg | F3 |
| HR 30-12T | 12 | 30.00 HR | 28.40 HR | 195.00 | 130.00 | 164.00 | 178.00 | 9.70kg | 10.20kg | F5/F6 |
| HR 33-12 | 12 | 33.00 HR | 31.20 HR | 195.00 | 130.00 | 164.00 | 178.00 | 10.20kg | 10.70kg | F5 |
| HR 35-12 | 12 | 35.00 HR | 33.10 HR | 195.00 | 130.00 | 164.00 | 178.00 | 11.20kg | 11.70kg | F5/F6 |
| HR 38-12 | 12 | 40.00 HR | 38.00 HR | 197.00 | 165.00 | 170.00 | 170.00 | 12.00kg | 12.50kg | F10/F6 |
| HR 40-12 | 12 | 42.00 HR | 40.00 HR | 197.00 | 165.00 | 170.00 | 170.00 | 12.50kg | 13.00kg | F10/F6 |
| HR 45-12 | 12 | 47.80 HR | 45.00 HR | 197.00 | 165.00 | 170.00 | 170.00 | 14.20kg | 14.70kg | F6 |
| HR 50-12 | 12 | 52.60 HR | 50.00 HR | 257.00 | 132.00 | 200.00 | 200.00 | 15.70kg | 16.20kg | F6 |
| HR 55-12 | 12 | 57.80 HR | 55.00 HR | 229.00 | 138.00 | 205.00 | 226.00 | 16.20kg | 16.70kg | F9/F6 |
| HR 60-12 | 12 | 62.40 HR | 60.00 HR | 260.00 | 168.00 | 208.00 | 228.00 | 18.40kg | 18.90kg | F9/F6 |
| HR 65-12 | 12 | 69.00 HR | 65.00 HR | 348.00 | 167.00 | 178.00 | 178.00 | 19.20kg | 19.70kg | F6/F10 |
| HR 70-12 | 12 | 73.60 HR | 70.00 HR | 348.00 | 167.00 | 178.00 | 178.00 | 21.00kg | 21.50kg | F6/F10 |
| HR 75-12 | 12 | 78.20 HR | 75.00 HR | 260.00 | 168.00 | 208.00 | 228.00 | 22.50kg | 23.00kg | F9/F6 |
| HR 80-12 | 12 | 85.60 HR | 80.00 HR | 260.00 | 168.00 | 208.00 | 214.00 | 23.00kg | 23.50kg | F6 |
| HR 90-12 | 12 | 94.60 HR | 90.00 HR | 330.00 | 173.00 | 212.00 | 220.00 | 25.00kg | 25.50kg | F11 |
| HR 100-12E | 12 | 103.00 HR | 100.00 HR | 330.00 | 173.00 | 212.00 | 220.00 | 28.20kg | 28.70kg | F11/F10 |
| HR 100-12 | 12 | 105.00 HR | 100.00 HR | 330.00 | 173.00 | 212.00 | 220.00 | 30.00kg | 30.50kg | F11/F10 |
| HR 120-12 | 12 | 123.40 HR | 120.00 HR | 408.00 | 177.00 | 225.00 | 225.00 | 35.00kg | 35.50kg | F11 |
| HR 135-12 | 12 | 140.40 HR | 135.00 HR | 345.00 | 172.00 | 274.00 | 280.00 | 40.00kg | 40.50kg | F11 |
| HR 150-12 | 12 | 157.00 HR | 150.00 HR | 483.00 | 170.00 | 238.00 | 238.00 | 43.20kg | 43.70kg | F11 |
| HR 180-12 | 12 | 189.00 HR | 532.00 HR | 532.00 | 207.00 | 214.00 | 220.00 | 51.00kg | 51.50kg | F11 |
| HR 200-12 | 12 | 208.00 HR | 200.00 HR | 522.00 | 240.00 | 218.00 | 224.00 | 57.00kg | 57.50kg | F11 |
| HR 200-12 | 12 | 208.00 HR | 200.00 HR | 522.00 | 240.00 | 218.00 | 224.00 | 58.00kg | 58.50kg | F11 |
| HR 200-12 | 12 | 208.00 HR | 200.00 HR | 522.00 | 240.00 | 218.00 | 224.00 | 59.80kg | 61.30kg | F11 |
| HR 250-12 | 12 | 262.00 HR | 250.00 HR | 522.00 | 268.00 | 220.00 | 226.00 | 70.00kg | 70.50kg | F11 |
| HR Series - 24V | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Model | Nominal Voltage (V) | Capacity (20hr) | Capacity (10hr) | Dimension (mm) | Net Weight | Gross Weight | Terminal | |||
| Length | Width | Height | Total Height | |||||||
| HR 1.3-24 | 24 | 1.30 HR | 1.18 HR | 193.00 | 42.00 | 52.00 | 58.00 | 1.05kg | 1.55kg | F1 |
| HR 3.5-24 | 24 | 3.60 HR | 3.28 HR | 185.00 | 74.00 | 70.00 | 70.00 | 2.50kg | 3.00kg | F2 |
| HR 4-24 | 24 | 4.00 HR | 3.70 HR | 140.00 | 90.00 | 103.00 | 109.00 | 3.00kg | 3.50kg | F1/F2 |
| HR 5-24 | 24 | 5.00 HR | 4.60 HR | 140.00 | 90.00 | 103.00 | 109.00 | 3.20kg | 3.70kg | F1/F2 |
